微信打开Standard Design Features
•Cryogenic Service to -196 C
•Forged or Cast Steel Body
•Floating & Trunnion Mounted Ball
•Extended Bonnet
•Lip Seal
•Cavity Pressure Relief
•Anti Blow-Out proof Stem
•Anti-Static Device
•Fire Safe Design
•In House Cryogenic Testing (On Request)
Production Range
•Valve size : 1/2″~24″ (DN15-DN600)
•Pressure : ASME Class150~1500 (PN20-PN250)
•Temperature : -196℃~ 200℃
•Body Materials :
Stainless Steel, Cryogenic Alloy Steel, Dual-Stainless steel
•Trim (Ball/Seat Ring/Stem) :
Stainless, Cryogenic resistant with nonmetal seal seat/ring
Design Standards
•Design : ASME 16.34/API 6D
MESC 77/200
BS 6364
•Face to Face : ASME B16.10
•BW End : ASME B16.25
•Test : API 598/BS 6755/API6D
•Fire Safe Test : API 607/API 6FA
•Special : NACE MR-01-75
