微信打开Standard Design Features
•Two Piece Split Body
•Floating & Trunnion Mounted Ball
•Anti Blow-Out proof Stem
•Anti-Static Device
•Seat : PTFE, RPTFE, PEEK, DEVLON V
•L-PORT, T-PORT
Production Range
•Valve size : 1/2″~8″ (DN15-DN200)
•Pressure : ASME Class 150~600 (PN20-PN420)
•Temperature: -46℃~ 200℃
•Body Materials : Carbon Steel, Stainless Steel, Alloy Steel, Duplex Steel, Ni-Al Bronze
•Trim : Carbon Steel, Stainless Steel, Duplex Steel, Ni-Al Bronze
•End Connection : RF, FF
Design Standards
•Design : ASME 16.34/API 6D
•Face to Face : Manufacturer’s standard
•End Flange : ASME B16.5
•BW End : ASME B16.25
•Test : API 598/BS 6755/API 6D
•Special : NACE MR-01-75, MR-01-03
